2.125″ Bore x 18″ Stroke Hydraulic Cylinder

Description

Cylinder Rating:

• Cylinder Pressure Rating: 2,500 PSI
• Operating Temperature Range: -40 F to 200 F
• Minimum Structural Safety Factor: 2:1
• Minimum Wall Burst Pressure: 13,650 PSI
• Minimum Recommended Rod Speed: 100 FT/MIN
  • • ***ROD SPEEDS UNDER 5 FT/MIN MAY CAUSE SEAL NOISE DUE TO STICK/SLIP
• Recommended maximum column load at full extension with 2:1 safety factor, no side load, pinned ends and no intermediate bracing: 17,700 LBS

Product Details:

• Bore – 2.125
• Rod Diameter – 1.500
• Stroke – 18.000
• Port – 3/8 NPTF
